Cross Triggering Unit (CTU) RM0046

634/936 Doc ID 16912 Rev 5

24.8.13 FIFO threshold register (FTH)

OF_EN1

FIFO 1 threshold Overflow interrupt enable

0Disabled

1 Enabled

EMPTY_EN1

FIFO 1 Empty interrupt enable

0Disabled

1 Enabled

FULL_EN1

FIFO 1 Full interrupt enable

0Disabled

1 Enabled

OR_EN0

FIFO 0 Overrun interrupt enable

0Disabled

1 Enabled

OF_EN0

FIFO 0 threshold Overflow interrupt enable

0Disabled

1 Enabled

EMPTY_EN0

FIFO 0 Empty interrupt enable

0Disabled

1 Enabled

FULL_EN0

FIFO 0 Full interrupt enable

0Disabled

1 Enabled

Table 329. FCR field descriptions (continued)

Field Description

Figure 322. FIFO threshold register (FTH)

Address:

Base + 0x0074 Access: User read/write

0123456789101112131415

TH3

TH2

Reset0000000000000000

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31

TH1 TH0

Reset0000000000000000

Table 330. FTH field descriptions

Field Description

TH3 FIFO 3 Threshold

TH2 FIFO 2 Threshold
