ST SPC560P34 - Figure 44. Mode Control Register (ME_MCTL)

RM0046 Mode Entry Module (MC_ME)
Doc ID 16912 Rev 5 149/936
Mode Control Register (ME_MCTL)
This register is used to trigger software-controlled mode changes. Depending on the modes
as enabled by ME_ME register bits, configurations corresponding to unavailable modes are
reserved and access to ME_<mode>_MC registers must respect this for successful mode
requests.
Note: Byte and half-word write accesses are not allowed for this register as a predefined key is
required to change its value.
Figure 44. Mode Control Register (ME_MCTL)
Address 0xC3FD_C004 Access: User read, Supervisor read/write, Test read/write
0123456789101112131415
R
TA R G ET_ MO D E
000000000000
W
Reset0011000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R1010010100001111
W KEY
Reset1010010100001111
