ST SPC560P34 - Table 475. Registers under Protection

Registers Under Protection RM0046
914/936 Doc ID 16912 Rev 5
Appendix A Registers Under Protection
For SPC560P40/34, the Register Protection module is operable on the registers listed in
Table 475.
Table 475. Registers under protection
Module Register Register size (bits) Register offset Protected bitfields
Code Flash—Base address: 0xC3F8_8000
4 registers to protect
Code Flash MCR 32 0x0000 bits[0:31]
Code Flash PFCR0 32 0x001C bits[0:31]
Code Flash PFCR1 32 0x0020 bits[0:31]
Code Flash PFAPR 32 0x0024 bits[0:31]
Data Flash—Base address: 0xC3F8_C000
1 register to protect
Data Flash MCR 32 0x0000 bits[0:31]
SIU lite—Base address: 0xC3F9_0000
97 registers to protect
SIUL IRER 32 0x0018 bits[0:31]
SIUL IREER 32 0x0028 bits[0:31]
SIUL IFEER 32 0x002C bits[0:31]
SIUL IFER 32 0x0030 bits[0:31]
SIUL PCR0 16 0x0040 bits[0:15]
SIUL PCR1 16 0x0042 bits[0:15]
SIUL PCR2 16 0x0044 bits[0:15]
SIUL PCR3 16 0x0046 bits[0:15]
SIUL PCR4 16 0x0048 bits[0:15]
SIUL PCR5 16 0x004A bits[0:15]
SIUL PCR6 16 0x004C bits[0:15]
SIUL PCR7 16 0x004E bits[0:15]
SIUL PCR8 16 0x0050 bits[0:15]
SIUL PCR9 16 0x0052 bits[0:15]
SIUL PCR10 16 0x0054 bits[0:15]
SIUL PCR11 16 0x0056 bits[0:15]
SIUL PCR12 16 0x0058 bits[0:15]
SIUL PCR13 16 0x005A bits[0:15]
