LIN checksum field register (LINCFR)
LIN control register 2 (LINCR2)
Figure 246. LIN checksum field register (LINCFR)
Offset: 0x002C Access: User read/write
0123456789101112131415
R 0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R 00000000
CF
W
Reset0000000000000000
Table 249. LINCFR field descriptions
Field Description
CF
Checksum bits
When LINCR1[CCD] = 0, this field is read-only. When LINCR1[CCD] = 1, this field is read/write.
See Table 235.
Figure 247. LIN control register 2 (LINCR2)
Offset: 0x0030 Access: User read/write
0123456789101112131415
R 0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R 0
IOBE IOPE
0 0 0 0 0 0 0 0 0 0 0 0 0
W WURQ DDRQ DTRQ ABRQ HTRQ
Reset0110000000000000
