RM0046 Cross Triggering Unit (CTU)
Doc ID 16912 Rev 5 629/936
24.8.9 Trigger handler control register 2 (THCR2)
Figure 317. Trigger handler control register 2 (THCR2)
Address: Base + 0x0028 Access: User read/write
0123456789101112131415
R000
T7_E
T7_
ETE
T7_
T1E
T7_
T0E
T7_
ADCE
000
T6_E
T6_
ETE
T6_
T1E
T6_
T0E
T6_
ADCE
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R000
T5_E
T5_
ETE
T5_
T5E
T5_
T0E
T5_
ADCE
000
T4_E
T4_
ETE
T4_
T1E
T4_
T0E
T4_
ADCE
W
Reset0000000000000000
Table 325. THCR2 field descriptions
Field Description
T7_E
Trigger 7 enable
0 Disabled
1Enabled
T7_ETE
Trigger 7 External Trigger output enable
0 Disabled
1Enabled
T7_T1E
Trigger 7 Timer 1 output enable
0 Disabled
1Enabled
T7_T0E
Trigger 7 Timer 0 output enable
0 Disabled
1Enabled
T7_ADCE
Trigger 7 ADC command output enable
0 Disabled
1Enabled
T6_E
Trigger 6 enable
0 Disabled
1Enabled
T6_ETE
Trigger 6 External Trigger output enable
0 Disabled
1Enabled
T6_T1E
Trigger 6 Timer 1 output enable
0 Disabled
1Enabled
T6_T0E
Trigger 6 Timer 0 output enable
0 Disabled
1Enabled
