RM0046 Reset Generation Module (MC_RGM)
Doc ID 16912 Rev 5 201/936
Table 64. Functional Bidirectional Reset Enable Register (RGM_FBRE) Field Descriptions
Field Description
BE_EXR
Bidirectional Reset Enable for External Reset
0RESET_B is asserted on an external reset event if the reset is enabled
1RESET_B is not asserted on an external reset event
BE_PLL1
Bidirectional Reset Enable for PLL1 fail
0RESET_B is asserted on a PLL1 fail event if the reset is enabled
1RESET_B is not asserted on a PLL1 fail event
BE_FLASH
Bidirectional Reset Enable for code or data flash fatal error
0RESET_B is asserted on a code or data flash fatal error event if the reset is enabled
1RESET_B is not asserted on a code or data flash fatal error event
BE_LVD45
Bidirectional Reset Enable for 4.5V low-voltage detected
0RESET_B is asserted on a 4.5V low-voltage detected event if the reset is enabled
1RESET_B is not asserted on a 4.5V low-voltage detected event
BE_CMU0_FHL
Bidirectional Reset Enable for CMU0 clock frequency higher/lower than reference
0RESET_B is asserted on a CMU0 clock frequency higher/lower than reference event if the
reset is enabled
1RESET_B is not asserted on a CMU0 clock frequency higher/lower than reference event
BE_CMU0_OLR
Bidirectional Reset Enable for oscillator frequency lower than reference
0RESET_B is asserted on a oscillator frequency lower than reference event if the reset is
enabled
1RESET_B is not asserted on a oscillator frequency lower than reference event
BE_PLL0
Bidirectional Reset Enable for PLL0 fail
0RESET_B is asserted on a PLL0 fail event if the reset is enabled
1RESET_B is not asserted on a PLL0 fail event
BE_CHKSTOP
Bidirectional Reset Enable for checkstop reset
0RESET_B is asserted on a checkstop reset event if the reset is enabled
1RESET_B is not asserted on a checkstop reset event
BE_SOFT
Bidirectional Reset Enable for software reset
0RESET_B is asserted on a software reset event if the reset is enabled
1RESET_B is not asserted on a software reset event
BE_CORE
Bidirectional Reset Enable for core reset
0RESET_B is asserted on a core reset event if the reset is enabled
1RESET_B is not asserted on a core reset event
BE_JTAG
Bidirectional Reset Enable for JTAG initiated reset
0RESET_B is asserted on a JTAG initiated reset event if the reset is enabled
1RESET_B is not asserted on a JTAG initiated reset event
