eTimer RM0046
712/936 Doc ID 16912 Rev 5
Capture register 2 (CAPT2)
This read only register stores the value captured from the counter. Exactly when a capture
occurs is defined by the CPT2MODE bits. This is actually a 2-deep FIFO and not a single
register. This register is not byte accessible.
Load register (LOAD)
This read/write register stores the value used to initialize the counter. This register is not
byte accessible.
Table 367. CAPT1 field descriptions
Field Description
CAPT1[15:0]
Capture 1
Stores the value captured from the counter.
This register is not byte accessible.
Figure 395. Capture register 2 (CAPT2)
Address:
Base + 0x0006 (eTimer0)
Base + 0x0026 (eTimer1)
Base + 0x0046 (eTimer2)
Base + 0x0066 (eTimer3)
Base + 0x0086 (eTimer4)
Base + 0x00A6 (eTimer5)
Access: User read-only
0123456789101112131415
R CAPT2[15:0]
W
Reset0000000000000000
Table 368. CAPT2 field descriptions
Field Description
CAPT2[15:0]
Capture 2
Stores the value captured from the counter.
This register is not byte accessible.
Figure 396. Load register (LOAD)
Address:
Base + 0x0008 (eTimer0)
Base + 0x0028(eTimer1)
Base + 0x0048 (eTimer2)
Base + 0x0068 (eTimer3)
Base + 0x0088 (eTimer4)
Base + 0x00A8 (eTimer5)
Access: User read/write
0123456789101112131415
R
LOAD[15:0]
W
Reset0000000000000000
