ST SPC560P34 - Auxiliary Clock 0 Select Control Register (CGM_AC0_SC); Table 30. Auxiliary Clock 0 Select Control Register (CGM_AC0_SC) Field Descriptions; Figure 31. Auxiliary Clock 0 Select Control Register (CGM_AC0_SC)

RM0046 Clock Generation Module (MC_CGM)
Doc ID 16912 Rev 5 127/936
5.5.5 Auxiliary Clock 0 Select Control Register (CGM_AC0_SC)
This register is used to select the current clock source for the following clocks:
● undivided: (unused)
● divided by auxiliary clock 0 divider 0: (unused)
See Figure 40 for details.
Figure 31. Auxiliary Clock 0 Select Control Register (CGM_AC0_SC)
Address 0xC3FE_0380 Access: User read, Supervisor read/write, Test read/write
0123456789101112131415
R0000
SELCTL
00000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R0000000000000000
W
Reset0000000000000000
Table 30. Auxiliary Clock 0 Select Control Register (CGM_AC0_SC) Field Descriptions
Field Description
SELCTL
Auxiliary Clock 0 Source Selection Control — This value selects the current source for auxiliary clock
0.
0000 (no clock)
0001 reserved
0010 (no clock)
0011 reserved
0100 (no clock)
0101 (no clock)
0110 reserved
0111 reserved
1000 (no clock)
1001 reserved
1010 reserved
1011 reserved
1100 reserved
1101 reserved
1110 reserved
1111 reserved
