Cross Triggering Unit (CTU) RM0046
624/936 Doc ID 16912 Rev 5
24.8.2 Trigger Generator Sub-unit Control Register (TGSCR)
24.8.3 Trigger x Compare Register (TxCR, x = 0...7)
I0_FE
Input 0 — PWM Reload Falling edge Enable
0 Disabled
1 Enabled
I0_RE
Input 0 — PWM Reload Rising edge Enable
0 Disabled
1 Enabled
Table 317. TGSISR field descriptions (continued)
Field Description
Figure 310. Trigger Generator Sub-unit Control Register (TGSCR)
Address: Base + 0x0004 Access: User read/write
0123456789101112131415
R0000000
ET_
TM
PRES MRS_SM
TGS
_M
W
Reset0000000000000000
Table 318. TGSCR field descriptions
Field Description
ET_TM This bit enables toggle mode for external triggers.
PRES
TGS and SU prescaler selection bits
00 1
01 2
10 3
11 4
MRS_SM Master Reload Selection in Sequential Mode (5 bits to select one of 32 inputs)
TGS_M
Trigger Generator Subunit Mode
0 Triggered Mode
1 Sequential Mode
Figure 311. Trigger x Compare Register (TxCR, x = 0...7)
Address:
Base + 0x0006 (T0CR)
Base + 0x0008 (T1CR)
Base + 0x000A (T2CR)
Base + 0x000C (T3CR)
Base + 0x000E (T4CR)
Base + 0x0010 (T5CR)
Base + 0x0012 (T6CR)
Base + 0x0014 (T7CR) Access: User read/write
0123456789101112131415
R
TxCRV
W
Reset0000000000000000
