ST SPC560P34 - Page 623

RM0046 Cross Triggering Unit (CTU)
Doc ID 16912 Rev 5 623/936
I7_FE
Input 7 — PWM OUT_TRIG 1 [2] Falling edge Enable
0 Disabled
1 Enabled
I7_RE
Input 7 — PWM OUT_TRIG 1 [2] Rising edge Enable
0 Disabled
1 Enabled
I6_FE
Input 6 — PWM OUT_TRIG 1 [1] Falling edge Enable
0 Disabled
1 Enabled
I6_RE
Input 6 — PWM OUT_TRIG 1 [1] Rising edge Enable
0 Disabled
1 Enabled
I5_FE
Input 5 — PWM OUT_TRIG 1 [0] Falling edge Enable
0 Disabled
1 Enabled
I5_RE
Input 5 — PWM OUT_TRIG 1 [0] Rising edge Enable
0 Disabled
1 Enabled
I4_FE
Input 4 — PWM OUT_TRIG 0 [3] Falling edge Enable
0 Disabled
1 Enabled
I4_RE
Input 4 — PWM OUT_TRIG 0 [3] Rising edge Enable
0 Disabled
1 Enabled
I3_FE
Input 3 — PWM OUT_TRIG 0 [2] Falling edge Enable
0 Disabled
1 Enabled
I3_RE
Input 3 — PWM OUT_TRIG 0 [2] Rising edge Enable
0 Disabled
1 Enabled
I2_FE
Input 2 — PWM OUT_TRIG 0 [1] Falling edge Enable
0 Disabled
1 Enabled
I2_RE
Input 2 — PWM OUT_TRIG 0 [1] Rising edge Enable
0 Disabled
1 Enabled h
I1_FE
Input 1 — PWM OUT_TRIG 0 [0] Falling edge Enable
0 Disabled
1 Enabled
I1_RE
Input 1 — PWM OUT_TRIG 0 [0] Rising edge Enable
0 Disabled
1 Enabled
Table 317. TGSISR field descriptions (continued)
Field Description
