Analog-to-Digital Converter (ADC) RM0046
600/936 Doc ID 16912 Rev 5
Injected Conversion Mask Registers (JCMR[0])
JCMR0 = Enable bits of injected sampling for channel 0 to 15 (precision channels)
Figure 297. Normal Conversion Mask Register 0 (NCMR0)
Address: Base + 0x00A4 Access: User read/write
0123456789101112131415
R00000000 00000 000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
CH15 CH14 CH13 CH12 CH11 CH10 CH9 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1 CH0
W
Reset0000000000000000
Table 306. NCMR field descriptions
Field Description
CHn
Sampling enable
When set Sampling is enabled for channel n.
Figure 298. Injected Conversion Mask Register 0 (JCMR0)
Address: Base + 0x00B4 Access: User read/write
0123456789101112131415
R00000000 00000 000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
CH15 CH14 CH13 CH12 CH11 CH10 CH9 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1 CH0
W
Reset0000000000000000
Table 307. JCMR field descriptions
Field Description
CHn
Sampling enable
When set, sampling is enabled for channel n.
