ST SPC560P34 - Figure 330. Cross Triggering Unit Control Register (CTUCR); Table 337. COTR Field Descriptions; Table 338. CTUCR Field Descriptions

RM0046 Cross Triggering Unit (CTU)
Doc ID 16912 Rev 5 641/936
24.8.21 Cross triggering unit control register (CTUCR)
Table 337. COTR field descriptions
Field Description
COTR Control ON-Time and Guard Time for external trigger
Figure 330. Cross triggering unit control register (CTUCR)
Address: Base + 0x00C8 Access: User read/write
0123456789101112131415
R
T7_SG T6_SG T5_SG T4_SG T3_SG T2_SG T1_SG T0_SG
CRU_ADC_R
CTU_ODIS
FE
CGRE
FGRE
MRS_SG
GRE
TGSISR_RE
W
Reset0000000000000000
Table 338. CTUCR field descriptions
Field Description
T7_SG
Trigger 7 Software Generated
0 Trigger has not been generated.
1 Trigger has been generated.
T6_SG
Trigger 6 Software Generated
0 Trigger has not been generated.
1 Trigger has been generated.
T5_SG
Trigger 5 Software Generated
0 Trigger has not been generated.
1 Trigger has been generated.
T4_SG
Trigger 4 Software Generated
0 Trigger has not been generated.
1 Trigger has been generated.
T3_SG
Trigger 3 Software Generated
0 Trigger has not been generated.
1 Trigger has been generated.
T2_SG
Trigger 2 Software Generated
0 Trigger has not been generated.
1 Trigger has been generated.
T1_SG
Trigger 1 Software Generated
0 Trigger has not been generated.
1 Trigger has been generated.
T0_SG
Trigger 0 Software Generated
0 Trigger has not been generated.
1 Trigger has been generated.
CRU_ADC_R CTU/ADC state machine Reset
CTU_ODIS CTU Output Disable
