System Integration Unit Lite (SIUL) RM0046
256/936 Doc ID 16912 Rev 5
Interrupt Rising-Edge Event Enable Register (IREER)
This register allows rising-edge triggered events to be enabled on the corresponding
interrupt pads.
Interrupt Falling-Edge Event Enable Register (IFEER)
This register allows falling-edge triggered events to be enabled on the corresponding
interrupt pads.
Figure 102. Interrupt Rising-Edge Event Enable Register (IREER)
Address: Base + 0x0028 Access: User read/write
0123456789101112131415
R
IREE[24:16]
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
IREE[15:0]
W
Reset0000000000000000
Table 95. IREER field descriptions
Field Description
IREEn
Enable rising-edge events to cause the EIFn bit to be set.
0: Rising-edge event disabled
1: Rising-edge event enabled
Figure 103. Interrupt Falling-Edge Event Enable Register (IFEER)
Address: Base + 0x002C Access: User read/write
0123456789101112131415
R
IFEE[24:16]
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
IFEE[15:0]
W
Reset0000000000000000
Table 96. IFEER field descriptions
Field Description
IFEEn
Enable falling-edge events to cause the EIFn bit to be set.
0: Falling-edge event disabled
1: Falling-edge event enabled
