RM0046 FlexCAN

Doc ID 16912 Rev 5 541/936

Figure 264. Rx FIFO structure

012345678910111213141516171819202122232425262728293031

0x0

SRR

IDE

RTR

LENGTH TIME STAMP

0x4

ID (Standard/Extended) ID (Extended)

0x8 Data Byte 0 Data Byte 1 Data Byte 2 Data Byte 3

0xC Data Byte 4 Data Byte 5 Data Byte 6 Data Byte 7

0x10

Reservedto

0xDF

0xE0 ID Table 0

0xE4 ID Table 1

0xE8 ID Table 2

0xEC ID Table 3

0xF0 ID Table 4

0xF4 ID Table 5

0xF8 ID Table 6

0xFC ID Table 7

= Unimplemented or Reserved

Table 271. ID Table 0 - 7

012345678910111213141516171819202122232425262728293031

REM

EXT

RXIDA

(Standard = 2-12, Extended = 2-31)

REM

EXT

RXIDB_0

(Standard =2-12, Extended = 2-15)

REM

EXT

RXIDB_1

(Standard = 18-28, Extended = 18-31)

RXIDC_0

(Std/Ext = 0-7)

RXIDC_1

(Std/Ext = 8-15)

RXIDC_2

(Std/Ext = 16-23)

RXIDC_3

(Std/Ext = 24-31)

= Unimplemented or Reserved
