FlexPWM RM0046
648/936 Doc ID 16912 Rev 5
25.6 Memory map and registers
25.6.1 FlexPWM module memory map
Table 342. FlexPWM memory map
Offset from
FlexPWM_BASE
(0xFFE2_4000)
Register
Access
Reset
value
Location
0x0000 CNT—Counter Register (Submodule 0) R 0x0000 on page 25-651
0x0002 INIT—Initial Count Register (Submodule 0) R/W 0x0000 on page 25-651
0x0004 CTRL2—Control 2 Register (Submodule 0) R/W 0x0000 on page 25-652
0x0006 CTRL1—Control 1 Register (Submodule 0) R/W 0x0000 on page 25-654
0x0008 VAL0—Value Register 0 (Submodule 0) R/W 0x0000 on page 25-656
0x000A VAL1—Value Register 1 (Submodule 0) R/W 0x0000 on page 25-657
0x000C VAL2—Value Register 2 (Submodule 0) R/W 0x0000 on page 25-657
0x000E VAL3—Value Register 3 (Submodule 0) R/W 0x0000 on page 25-658
0x0010 VAL4—Value Register 4 (Submodule 0) R/W 0x0000 on page 25-658
0x0012 VAL5—Value Register 5 (Submodule 0) R/W 0x0000 on page 25-659
0x0014–0x0017 Reserved
0x0018 OCTRL—Output Control Register (Submodule 0) R/W 0x0000 on page 25-659
0x001A STS—Status Register (Submodule 0) R/W 0x0000 on page 25-660
0x001C INTEN—Interrupt Enable Register (Submodule 0) R/W 0x0000 on page 25-661
0x001E DMAEN—DMA Enable Register (Submodule 0) R/W 0x0000 on page 25-662
0x0020 TCTRL—Output Trigger Control Register (Submodule 0) R/W 0x0000 on page 25-663
0x0022
DISMAP—Fault Disable Mapping Register (Submodule
0)
R/W 0xFFFF on page 25-664
0x0024 DTCNT0—Deadtime Count Register 0 (Submodule 0) R/W 0x07FF on page 25-664
0x0026 DTCNT1—Deadtime Count Register 1 (Submodule 0) R/W 0x07FF on page 25-664
0x0028–0x004F Reserved
0x0050 CNT—Counter Register (Submodule 1) R 0x0000 on page 25-651
0x0052 INIT—Initial Count Register (Submodule 1) R/W 0x0000 on page 25-651
0x0054 CTRL2—Control 2 Register (Submodule 1) R/W 0x0000 on page 25-652
0x0056 CTRL1—Control 1 Register (Submodule 1) R/W 0x0000 on page 25-654
0x0058 VAL0—Value Register 0 (Submodule 1) R/W 0x0000 on page 25-656
0x005A VAL1—Value Register 1 (Submodule 1) R/W 0x0000 on page 25-657
0x005C VAL2—Value Register 2 (Submodule 1) R/W 0x0000 on page 25-657
0x005E VAL3—Value Register 3 (Submodule 1) R/W 0x0000 on page 25-658
0x0060 VAL4—Value Register 4 (Submodule 1) R/W 0x0000 on page 25-658
