RM0046 FlexPWM
Doc ID 16912 Rev 5 649/936
0x0062 VAL5—Value Register 5 (Submodule 1) R/W 0x0000 on page 25-659
0x0064–0x0067 Reserved
0x0068 OCTRL—Output Control Register (Submodule 1) R/W 0x0000 on page 25-659
0x006A STS—Status Register (Submodule 1) R/W 0x0000 on page 25-660
0x006C INTEN—Interrupt Enable Register (Submodule 1) R/W 0x0000 on page 25-661
0x006E DMAEN—DMA Enable Register (Submodule 1) R/W 0x0000 on page 25-662
0x0070 TCTRL—Output Trigger Control Register (Submodule 1) R/W 0x0000 on page 25-663
0x0072
DISMAP—Fault Disable Mapping Register (Submodule
1)
R/W 0xFFFF on page 25-664
0x0074 DTCNT0—Deadtime Count Register 0 (Submodule 1) R/W 0x07FF on page 25-664
0x0076 DTCNT1—Deadtime Count Register 1 (Submodule 1) R/W 0x07FF on page 25-664
0x0078–0x009F Reserved
0x00A0 CNT—Counter Register (Submodule 2) R 0x0000 on page 25-651
0x00A2 INIT—Initial Count Register (Submodule 2) R/W 0x0000 on page 25-651
0x00A4 CTRL2—Control 2 Register (Submodule 2) R/W 0x0000 on page 25-652
0x00A6 CTRL1—Control 1 Register (Submodule 2) R/W 0x0000 on page 25-654
0x00A8 VAL0—Value Register 0 (Submodule 2) R/W 0x0000 on page 25-656
0x00AA VAL1—Value Register 1 (Submodule 2) R/W 0x0000 on page 25-657
0x00AC VAL2—Value Register 2 (Submodule 2) R/W 0x0000 on page 25-657
0x00AE VAL3—Value Register 3 (Submodule 2) R/W 0x0000 on page 25-658
0x00B0 VAL4—Value Register 4 (Submodule 2) R/W 0x0000 on page 25-658
0x00B2 VAL5—Value Register 5 (Submodule 2) R/W 0x0000 on page 25-659
0x00B4–0x00B7 Reserved
0x00B8 OCTRL—Output Control Register (Submodule 2) R/W 0x0000 on page 25-659
0x00BA STS—Status Register (Submodule 2) R/W 0x0000 on page 25-660
0x00BC INTEN—Interrupt Enable Register (Submodule 2) R/W 0x0000 on page 25-661
0x00BE DMAEN—DMA Enable Register (Submodule 2) R/W 0x0000 on page 25-662
0x00C0 TCTRL—Output Trigger Control Register (Submodule 2) R/W 0x0000 on page 25-663
0x00C2
DISMAP—Fault Disable Mapping Register (Submodule
2)
R/W 0xFFFF on page 25-664
0x00C4 DTCNT0—Deadtime Count Register 0 (Submodule 2) R/W 0x07FF on page 25-664
0x00C6 DTCNT1—Deadtime Count Register 1 (Submodule 2) R/W 0x07FF on page 25-664
0x00C8–0x00EF Reserved
0x00F0 CNT—Counter Register (Submodule 3) R 0x0000 on page 25-651
Table 342. FlexPWM memory map (continued)
Offset from
FlexPWM_BASE
(0xFFE2_4000)
Register Access
Reset
value
Location
