SWT Window Register (SWT_WN)
The SWT Window (SWT_WN) register contains the 32-bit window start value. This register
is cleared on reset. This register is read only if either the SWT_CR[HLK] or SWT_CR[SLK]
bits are set.
Table 394. SWT_TO field descriptions
Field Description
WTO
Watchdog time-out period in clock cycles
An internal 32-bit down counter is loaded with this value or 0x0100, whichever is greater when the
service sequence is written or when the SWT is enabled.
Figure 431. SWT Window register (SWT_WN)
Address:
Base + 0x000C Access: User read/write
0123456789101112131415
R
WST
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
WST
W
Reset0000000000000000
Table 395. SWT_WN field descriptions
Field Description
WST
Window start value
When window mode is enabled, the service sequence can only be written when the internal down
counter is less than this value.
