FlexPWM RM0046
668/936 Doc ID 16912 Rev 5
Note: These bits are double buffered and do not take effect until a FORCE_OUT event occurs
within the appropriate submodule. Refer to Figure 373 to see how FORCE_OUT is
generated. Reading these bits reads the buffered value and not necessarily the value
currently in effect.
Deadtime Source Select Register (DTSRCSEL)
11
OUTB_2
Software Controlled Output B_2
This bit is only used when SELB for submodule 2 is set to 0b10. It allows software control of which
signal is supplied to the deadtime generator of that submodule.
0 A logic 0 is supplied to the deadtime generator of submodule 2 instead of PWMB.
1 A logic 1 is supplied to the deadtime generator of submodule 2 instead of PWMB.
12
OUTA_1
Software Controlled Output A_1
This bit is only used when SELA for submodule 1 is set to 0b10. It allows software control of which
signal is supplied to the deadtime generator of that submodule.
0 A logic 0 is supplied to the deadtime generator of submodule 1 instead of PWMA.
1 A logic 1 is supplied to the deadtime generator of submodule 1 instead of PWMA.
13
OUTB_1
Software Controlled Output B_1
This bit is only used when SELB for submodule 1 is set to 0b10. It allows software control of which
signal is supplied to the deadtime generator of that submodule.
0 A logic 0 is supplied to the deadtime generator of submodule 1 instead of PWMB.
1 A logic 1 is supplied to the deadtime generator of submodule 1 instead of PWMB.
14
OUTA_0
Software Controlled Output A_0
This bit is only used when SELA for submodule 0 is set to 0b10. It allows software control of which
signal is supplied to the deadtime generator of that submodule.
0 A logic 0 is supplied to the deadtime generator of submodule 0 instead of PWMA.
1 A logic 1 is supplied to the deadtime generator of submodule 0 instead of PWMA.
15
OUTB_0
Software Controlled Output BA_0
This bit is only used when SELB for submodule 0 is set to 0b10. It allows software control of which
signal is supplied to the deadtime generator of that submodule.
0 A logic 0 is supplied to the deadtime generator of submodule 0 instead of PWMB.
1 A logic 1 is supplied to the deadtime generator of submodule 0 instead of PWMB.
Table 355. SWCOUT field descriptions (continued)
Field Description
Figure 356. Deadtime Source Select Register (DTSRCSEL)
Address:
Base + 0x0146 Access: User read/write
0123456789101112131415
R
SELA_3 SELB_3 SELA_2 SELB_2 SELA_1 SELB_1 SELA_0 SELB_0
W
Reset0000000000000000
