RM0046 Fault Collection Unit (FCU)
Doc ID 16912 Rev 5 763/936
Frozen Fault Flag Register (FCU_FFFR)
The Fault Flag Register (FCU_FFR) is copied into Frozen Fault Flag Register (FFFR) every
time the FCU goes into Fault state, in order to take a snapshot of the fault flags.
The bit description of the FCU_FFFR is the same as that of the FCU_FFR. The FCU_FFR is
read/clear whereas the FCU_FFFR is read-only. See Figure 439 and Tabl e 4 04 for details.
HRF5 Not used
HRF6 Not used
HRF7 Flash Flash Fatal Error
HRF8 SWT SW Watchdog reset
HRF9 JTAG JTAG reset (TAP controller)
HRF10 PMU Comparators
HRF11 PMU LVD 4.5
HRF12 PMU LVD 2.7 VREG
HRF13 PMU LVD 2.7 FLASH
HRF14 PMU LVD 2.7 I/O
HRF15 PMU LVD 1.2 digital
SRF0 FCU FCU error
SRF1 FCU Software-triggered error
SRF2 SRAM ECC multi-bit error
SRF3 Data Flash ECC multi-bit error
SRF4 Code Flash ECC multi-bit error
Table 403. Hardware/software fault description (continued)
Label Module Fault type
Figure 439. Frozen Fault Flag Register (FCU_FFFR)
Address: Base + 0x0008 Access: User read-only
0123456789101112131415
R
FRS
RF0
FRS
RF1
FRS
RF2
FRS
RF3
FRS
RF4
00000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
FRH
RF15
FRH
RF14
FRH
RF13
FRH
RF12
FRH
RF11
FRH
RF10
FRH
RF9
FRH
RF8
FRH
RF7
FRH
RF6
FRH
RF5
FRH
RF4
FRH
RF3
FRH
RF2
FRH
RF1
FRH
RF0
W
Reset0000000000000000
