ST SPC560P34 - Table 399. FCU Memory Map; Table 400. Register Summary

Fault Collection Unit (FCU) RM0046
758/936 Doc ID 16912 Rev 5
28.2.1 Memory map
28.2.2
Register summary
Table 400 shows the register summary.
Table 399. FCU memory map
Offset from
FCU_BASE
(0xFFE6_C000)
Register Location
0x0000 Module Configuration Register (FCU_MCR) on page 28-760
0x0004 Fault Flag Register (FCU_FFR) on page 28-761
0x0008 Frozen Fault Flag Register (FCU_FFFR) on page 28-763
0x000C Fake Fault Generation Register (FCU_FFGR) on page 28-764
0x0010 Fault Enable Register (FCU_FER) on page 28-765
0x0014 Key Register (FCU_KR) on page 28-765
0x0018 Timeout Register (FCU_TR) on page 28-766
0x001C Timeout Enable Register (FCU_TER) on page 28-767
0x0020 Module State Register (FCU_MSR) on page 28-767
0x0024 Microcontroller State Register (FCU_MCSR) on page 28-768
0x0028 Frozen MC State Register (FCU_FMCSR) on page 28-770
0x002C–0x3FFF Reserved
Table 400. Register summary
Name
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
0x0000_0000
FCU_MCR
R
MCL TM
[1:0]
00000 0 0 000000
W
R0 0 0000
PS
[1:0] FOM [1:0] FOP [5:0]
W
0x0000_0004
FCU_FFR
R
SRF0 SRF1 SRF2 SRF3 SRF4
000 0 0 000000
W
R
HRF15 HRF14 HRF13 HRF12 HRF11 HRF10
HRF9 HRF8 HRF7 HRF6 HRF5 HRF4 HRF3 HRF2 HRF1 HRF0
W
