ST SPC560P34 - Table 252. BDRL Field Descriptions; Figure 249. Buffer Data Register LSB (BDRL); Figure 250. Buffer Data Register MSB (BDRM)

LIN Controller (LINFlex) RM0046
512/936 Doc ID 16912 Rev 5
Buffer data register LSB (BDRL)
Buffer data register MSB (BDRM)
Figure 249. Buffer data register LSB (BDRL)
Offset: 0x0038 Access: User read/write
0123456789101112131415
R
DATA3 DATA2
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
DATA1 DATA0
W
Reset0000000000000000
Table 252. BDRL field descriptions
Field Description
DATA3
Data Byte 3
Data byte 3 of the data field.
DATA2
Data Byte 2
Data byte 2 of the data field.
DATA1
Data Byte 1
Data byte 1 of the data field.
DATA0
Data Byte 0
Data byte 0 of the data field.
Figure 250. Buffer data register MSB (BDRM)
Offset: 0x003C Access: User read/write
0123456789101112131415
R
DATA7 DATA6
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
DATA5 DATA4
W
Reset0000000000000000
