ST SPC560P34 - Table 313. TGS Registers; Table 314. SU Registers; Table 315. CTU Registers

Cross Triggering Unit (CTU) RM0046
620/936 Doc ID 16912 Rev 5
Table 313. TGS registers
Offset from
CTU_BASE
Register
Double-
buffere
d
Synchronizatio
n
Reset value
0x0000
TGSISR — Trigger Generator Subunit Input Selection
Register
Yes TGSISR_RE
0x0000_000
0
0x0004
TGSCRR — Trigger Generator Subunit Control
Register
Yes MRS 0x0000
0x0006 T0CR — Trigger 0 Compare Register Yes MRS 0x0000
0x0008 T1CR — Trigger 1 Compare Register Yes MRS 0x0000
0x000A T2CR — Trigger 2 Compare Register Yes MRS 0x0000
0x000C T3CR — Trigger 3 Compare Register Yes MRS 0x0000
0x000E T4CR — Trigger 4 Compare Register Yes MRS 0x0000
0x0010 T5CR — Trigger 5 Compare Register Yes MRS 0x0000
0x0012 T6CR — Trigger 6 Compare Register Yes MRS 0x0000
0x0014 T7CR — Trigger 7 Compare Register Yes MRS 0x0000
0x0016 TGSCCR — TGS Counter Compare Register Yes MRS 0x0000
0x0018 TGSCRR — TGS Counter Reload Register Yes MRS 0x0000
Table 314. SU registers
Offset from
CTU_BASE
Register
Double-
buffered
Synchronization Reset value
0x001C CLCR1 — Commands List Control Register 1 Yes MRS 0x0000_0000
0x0020 CLCR2 — Commands List Control Register 2 Yes MRS 0x0000_0000
0x0024 THCR1 — Trigger Handler Control Register 1 Yes MRS 0x0000_0000
0x0028 THCR2 — Trigger Handler Control Register 2 Yes MRS 0x0000_0000
0x002C –
0x005A
CLRx — Commands List Register x (x = 1,...,24) Yes MRS 0x0000
Table 315. CTU registers
Offset from
CTU_BASE
Register
Double-
buffered
Synchronization
Reset
value
0x00C0
CTUEFR — Cross Triggering Unit Error Flag
Register
No — 0x0000
0x00C2
CTUIFR — Cross Triggering Unit Interrupt Flag
Register
No — 0x0000
0x00C4 CTUIR — Cross Triggering Unit Interrupt Register No — 0x0000
0x00C6 COTR — Control ON-Time Register Yes MRS 0x0000
0x00C8 CTUCR — Cross triggering unit control register No — 0x0000
