24.8.16 FIFO signed Left aligned data x (x = 0,...,3) (FLx)
24.8.17 Cross triggering unit error flag register (CTUEFR)
Table 332. FRx field descriptions
Field Description
N_CH[4:0]
Number of stored channel
0xxxx: Result comes from an ADC_1 channel
1xxxx: Result comes from an ADC_0 channel
DATA Data of stored channel
Figure 325. FIFO signed Left aligned data x (x = 0,...,3) (FLx)
Address: Base + 0x00A0,...,0x00AC Access: User read-only
0123456789101112131415
R00000000 0 0 0 N_CH[4:0]
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R0 DATA 00000
W
Reset0000000000000000
Table 333. FLx field descriptions
Field Description
N_CH[4:0]
Number of stored channel
0xxxx: Result comes from an ADC_1 channel
1xxxx: Result comes from an ADC_0 channel
DATA Data of stored channel
Figure 326. Cross triggering unit error flag register (CTUEFR)
Address: Base + 0x00C0 Access: User read/write
0123456789101112131415
R0000000
ET_OE
T1_OE T0_OE
ADC_OE
TGS_OSM
MRS_O
ICE
SM_TO
MRS_RE
W
Reset0000000000000000
