ST SPC560P34 - Table 300. WTIMR Field Descriptions; Figure 291. Watchdog Threshold Interrupt Mask Register (WTIMR)

To Next Page

To Previous Page

Analog-to-Digital Converter (ADC) RM0046

594/936 Doc ID 16912 Rev 5

Watchdog Threshold Interrupt Mask Register (WTIMR)

Figure 291. Watchdog Threshold Interrupt Mask Register (WTIMR)

Address:

Base + 0x0034 Access: User read/write

0123456789101112131415

R00000000 00000 000

Reset0000000000000000

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31

R00000000

MSKWDG3H

MSKWDG2H

MSKWDG1H

MSKWDG0H

MSKWDG3L

MSKWDG2L

MSKWDG1L

MSKWDG0L

Reset0000000000000000

Table 300. WTIMR field descriptions

Field Description

MSKWDGxH

This corresponds to the mask bit for the interrupt generated on the converted value being higher

than the programmed higher threshold (for [x = 0..3]). When set the interrupt is enabled.

MSKWDGxL

This corresponds to the mask bit for the interrupt generated on the converted value being lower

than the programmed lower threshold (for [x = 0..3]). When set the interrupt is enabled.
