Fault Collection Unit (FCU) RM0046

770/936 Doc ID 16912 Rev 5

Frozen MC State Register (FCU_FMCSR)

The FCU_MCSR is copied into the FCU_FMCSR each time the Fault state is entered. The

FCU_FMCSR bit description is the same as that of the FCU_MCSR.

Figure 447. Frozen MC State Register (FCU_FMCSR)

Address:

Base + 0x0028 Access: User read-only, Supervisor read-only

0123456789101112131415

R00000000 0000 FRMCPS[3:0]

Reset0000000000000000

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31

R00000000 0000 FRMCAS[3:0]

Reset0000000000000000

Table 411. FCU_FMCSR field description

Field Description

12:15

FRMCPS

[3:0]

MC Previous State

0000: RESET

0001: TEST

0010: SAFE

0011: DRUN

0100: RUN0

0101: RUN1

0110: RUN2

0111: RUN3

1000: HALT0

1001: Reserved

1010: STOP

1011: Reserved

1100: Reserved

1101: Reserved

1110: Reserved

1111: Reserved
