RM0046 Error Correction Status Module (ECSM)
Doc ID 16912 Rev 5 287/936
15.4.1 Memory map
Table 112 lists the registers in the ECSM.
Table 112. ECSM registers
Offset from
ECSM_BASE
0xFFF4_0000
Register Location Size (bits)
0x0000 PCT—Processor Core Type register on page 15-288 16
0x0002 REV—Revision register on page 15-288 16
0x0004 PLAMC — Platform XBAR Master Configuration on page 15-289 16
0x0006 PLASC — Platform XBAR Sleave Configuration on page 15-289 16
0x0008 IMC—IPS Module Configuration register on page 15-290 16
0x000C–0x000E Reserved
0x000F MRSR—Miscellaneous Reset Status register on page 15-290 8
0x0010–0x001E Reserved
0x001F MIR—Miscellaneous Interrupt register on page 15-291 8
0x0020–0x0023 Reserved
0x0024 MUDCR—Miscellaneous User-Defined Control Register on page 15-292 32
0x0028–0x0042 Reserved
0x0043 ECR—ECC Configuration register on page 15-293 8
0x0044–0x0046 Reserved
0x0047 ESR—ECC Status register on page 15-294 8
0x0048–0x0049 Reserved
0x004A EEGR—ECC Error Generation register on page 15-296 16
0x004C–0x004F Reserved
0x0050 FEAR—Flash ECC Address register on page 15-298 32
0x0054–0x0055 Reserved
0x0056 FEMR—Flash ECC Master Number Register on page 15-299 8
0x0057 FEAT—Flash ECC Attributes register on page 15-299 8
0x0058–0x005B Reserved
0x005C FEDR—Flash ECC Data register on page 15-300 32
0x0060 REAR—RAM ECC Address register on page 15-301 32
0x0064 Reserved
0x0065 RESR—RAM ECC Syndrome register on page 15-302 8
0x0066 REMR—RAM ECC Master register on page 15-304 8
0x0067 REAT—RAM ECC Attributes register on page 15-304 8
0x0068–0x006B Reserved
