Deserial Serial Peripheral Interface (DSPI) RM0046
452/936 Doc ID 16912 Rev 5
Table 211. DSPI PCS to SCK delay scaler
CSSCK PCS to SCK delay scaler value CSSCK PCS to sck delay scaler value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
Table 212. DSPI after SCK delay scaler
ASC After SCK delay scaler value ASC After SCK delay scaler value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
Table 213. DSPI delay after transfer scaler
DT Delay after transfer scaler value DT Delay after transfer scaler value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
