Mode Entry Module (MC_ME) RM0046
154/936 Doc ID 16912 Rev 5
Invalid Mode Transition Status Register (ME_IMTS)
This register provides the status bits for the possible causes of an invalid mode interrupt.
Figure 48. Invalid Mode Transition Status Register (ME_IMTS)
Address 0xC3FD_C014 Access: User read, Supervisor read/write, Test read/write
0123456789101112131415
R0000000000000000
W
Reset0000000000000000
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R00000000000
S_MTI
S_MRI
S_DMA S_NMA
S_SEA
W w1c w1c w1c w1c w1c
Reset0000000000000000
Table 44. Invalid Mode Transition Status Register (ME_IMTS) Field Descriptions
Field Description
S_MTI
Mode Transition Illegal status — This bit is set whenever a new mode is requested while some
other mode transition process is active (S_MTRANS is ‘1’). Please refer to Section 6.4.5, “Mode
Transition Interrupts for the exceptions to this behavior. It is cleared by writing a ‘1’ to this bit.
0 Mode transition requested is not illegal
1 Mode transition requested is illegal
S_MRI
Mode Request Illegal status — This bit is set whenever the target mode requested is not a valid
mode with respect to current mode. It is cleared by writing a ‘1’ to this bit.
0 Target mode requested is not illegal with respect to current mode
1 Target mode requested is illegal with respect to current mode
S_DMA
Disabled Mode Access status — This bit is set whenever the target mode requested is one of
those disabled modes determined by ME_ME register. It is cleared by writing a ‘1’ to this bit.
0 Target mode requested is not a disabled mode
1 Target mode requested is a disabled mode
S_NMA
Non-existing Mode Access status — This bit is set whenever the target mode requested is one of
those non existing modes determined by ME_ME register. It is cleared by writing a ‘1’ to this bit.
0 Target mode requested is an existing mode
1 Target mode requested is a non-existing mode
S_SEA
SAFE Event Active status — This bit is set whenever the device is in SAFE mode, SAFE event bit
is pending and a new mode requested other than RESET/SAFE modes. It is cleared by writing a ‘1’
to this bit.
0 No new mode requested other than RESET/SAFE while SAFE event is pending
1 New mode requested other than RESET/SAFE while SAFE event is pending
