Cross Triggering Unit (CTU) RM0046
642/936 Doc ID 16912 Rev 5
24.8.22 Cross triggering unit digital filter (CTUDF)
24.8.23 Cross triggering unit power control register (CTUPCR)
DFE Digital Filter Enable
CGRE Clear GRE
FGRE Flag GRE
MRS_SG MRS Software Generated
GRE General Reload Enable
TGSISR_RE TGS Input Selection Register Reload Enable
Table 338. CTUCR field descriptions (continued)
Field Description
Figure 331. Cross triggering unit digital filter (CTUDF)
Address:
Base + 0x00CA Access: User read/write
0123456789101112131415
R00000000
N
W
Reset0000000000000000
Table 339. CTUDF field descriptions
Field Description
0-7 Reserved
8-15
N
Digital Filter value (the external signal is considered at 1 if it is latched N time at 1 and is
considered at 0 if it is latched N time at 0)
Figure 332. Cross triggering unit power control register (CTUPCR)
Address:
Base + 0x00CC Access: User read/write
0123456789101112131415
R0000000000000 00
MDIS
W
Reset0000000000000000
Table 340. CTUPCR field descriptions
Field Description
0-14 Reserved
15
MDIS
Module Disable
