Cross Triggering Unit (CTU) RM0046
622/936 Doc ID 16912 Rev 5
Table 317. TGSISR field descriptions
Field Description
I15_FE
Input 15 — ext_signals Falling edge Enable
0 Disabled
1 Enabled
I15_RE
Input 15 — ext_signals Rising edge Enable
0 Disabled
1 Enabled
I13_FE
Input 13 — eTimer0 [ETC2] Falling edge Enable
0 Disabled
1 Enabled
I13_RE
Input 13 — eTimer0 [ETC2] Rising edge Enable
0 Disabled
1 Enabled
I12_FE
Input 12 —PWM X[3] Falling edge Enable
0 Disabled
1 Enabled
I12_RE
Input 12 — PWM X[3] Rising edge Enable
0Disabled
1 Enabled
I11_FE
Input 11 — PWM X[2] Falling edge Enable
0 Disabled
1 Enabled
I11_RE
Input 11 — PWM X[2] Rising edge Enable
0 Disabled
1 Enabled
I10_FE
Input 10 — PWM X[1] Falling edge Enable
0Disabled
1 Enabled
I10_RE
Input 10 — PWM X[1] Rising edge Enable
0 Disabled
1 Enabled
I9_FE
Input 9 — PWM X[0] Falling edge Enable
0Disabled
1 Enabled
I9_RE
Input 9 — PWM X[0] Rising edge Enable
0 Disabled
1 Enabled
I8_FE
Input 8 — PWM OUT_TRIG 1 [3] Falling edge Enable
0 Disabled
1 Enabled
I8_RE
Input 8 — PWM OUT_TRIG 1 [3] Rising edge Enable
0 Disabled
1 Enabled
