RM0046 Mode Entry Module (MC_ME)

Doc ID 16912 Rev 5 151/936

Table 41. Mode Enable Register (ME_ME) Field Descriptions

Field Description

STOP0

STOP0 mode enable

0 STOP0 mode is disabled

1 STOP0 mode is enabled

HALT0

HALT0 mode enable

0 HALT0 mode is disabled

1 HALT0 mode is enabled

RUN3

RUN3 mode enable

0 RUN3 mode is disabled

1 RUN3 mode is enabled

RUN2

RUN2 mode enable

0 RUN2 mode is disabled

1 RUN2 mode is enabled

RUN1

RUN1 mode enable

0 RUN1 mode is disabled

1 RUN1 mode is enabled

RUN0

RUN0 mode enable

0 RUN0 mode is disabled

1 RUN0 mode is enabled

DRUN

DRUN mode enable

0 DRUN mode is disabled

1 DRUN mode is enabled

SAFE

SAFE mode enable

0 SAFE mode is disabled

1 SAFE mode is enabled

TEST

TEST mode enable

0 TEST mode is disabled

1 TEST mode is enabled

RESET

RESET mode enable

0 RESET mode is disabled

1 RESET mode is enabled
