Reset Generation Module (MC_RGM) RM0046
196/936 Doc ID 16912 Rev 5
Table 60. Functional Event Reset Disable Register (RGM_FERD) Field Descriptions
Field Description
D_EXR
Disable External Reset
0 An external reset event triggers a reset sequence
D_PLL1
Disable PLL1 fail
0 A PLL1 fail event triggers a reset sequence
1 A PLL1 fail event generates either a SAFE mode or an interrupt request depending on the value
of RGM_FEAR.AR_PLL1
D_FLASH
Disable code or data flash fatal error
0 A code or data flash fatal error event triggers a reset sequence
D_LVD45
Disable 4.5V low-voltage detected
0 A 4.5V low-voltage detected event triggers a reset sequence
1 A 4.5V low-voltage detected event generates either a SAFE mode or an interrupt request
depending on the value of RGM_FEAR.AR_LVD45
D_CMU0_FHL
Disable CMU0 clock frequency higher/lower than reference
0 A CMU0 clock frequency higher/lower than reference event triggers a reset sequence
1 A CMU0 clock frequency higher/lower than reference event generates either a SAFE mode or
an interrupt request depending on the value of RGM_FEAR.AR_CMU0_FHL
D_CMU0_OLR
Disable oscillator frequency lower than reference
0 A oscillator frequency lower than reference event triggers a reset sequence
1 A oscillator frequency lower than reference event generates either a SAFE mode or an interrupt
request depending on the value of RGM_FEAR.AR_CMU0_OLR
D_PLL0
Disable PLL0 fail
0 A PLL0 fail event triggers a reset sequence
1 A PLL0 fail event generates either a SAFE mode or an interrupt request depending on the value
of RGM_FEAR.AR_PLL0
D_CHKSTOP
Disable checkstop resetl
0 A checkstop reset event triggers a reset sequence
D_SOFT
Disable software reset
0 A software reset event triggers a reset sequence
D_CORE
Disable core reset
0 A core reset event triggers a reset sequence
1 A core reset event generates either a SAFE mode or an interrupt request depending on the
value of RGM_FEAR.AR_CORE
D_JTAG
Disable JTAG initiated reset
0 A JTAG initiated reset event triggers a reset sequence
1 A JTAG initiated reset event generates either a SAFE mode or an interrupt request depending
on the value of RGM_FEAR.AR_JTAG
