RM0046 LIN Controller (LINFlex)

Doc ID 16912 Rev 5 495/936

LIN interrupt enable register (LINIER)

0001 11-bit

0010 12-bit

0011 13-bit

0100 14-bit

0101 15-bit

0110 16-bit

0111 17-bit

1000 18-bit

1001 19-bit

1010 20-bit

1011 21-bit

1100 22-bit

1101 23-bit

1110 36-bit

1111 50-bit

Table 237. Operating mode selection

SLEEP INIT Operating mode

1 0 Sleep (reset value)

x 1 Initialization

00Normal

Table 236. LIN master break length selection (continued)

MBL Length

Figure 236. LIN interrupt enable register (LINIER)

Offset: 0x0004 Access: User read/write

0123456789101112131415

R 0000000000000000

Reset0000000000000000

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31

SZIE OCIE BEIE CEIE HEIE

FEIE BOIE LSIE

WUIE

DBFIE DBEIE

DRIE DTIE HRIE

Reset0000000000000000
