RM0046 Mode Entry Module (MC_ME)

Doc ID 16912 Rev 5 147/936

Global Status Register (ME_GS)

This register contains global mode status.

Figure 43. Global Status Register (ME_GS)

Address 0xC3FD_C000 Access: User read, Supervisor read, Test read

0123456789101112131415

R S_CURRENT_MODE

S_MTRANS

100

S_PDO

S_MVR

S_DFLA S_CFLA

Reset0000110000011111

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31

R000000000

S_PLL0

S_XOSC0

S_16 MHz_IRC

S_SYSCLK

Reset0000000000010000

Table 39. Global Status Register (ME_GS) Field Descriptions

Field Description

S_CURRENT

_MODE

Current device mode status

0000 RESET

0001 TEST

0010 SAFE

0011 DRUN

0100 RUN0

0101 RUN1

0110 RUN2

0111 RUN3

1000 HALT0

1001 reserved

1010 STOP0

1011 reserved

1100 reserved

1101 reserved

1110 reserved

1111 reserved

S_MTRANS

Mode transition status

0 Mode transition process is not active

1 Mode transition is ongoing
