Document revision history
Table 476 summarizes revisions to this document.
Table 476. Revision history
Date Revision Changes
10-Dec-2009 1 Initial release
30-Jun-2010 2
Preface
Organization:
– Corrected cross-reference to Nexus chapter
– Removed bullet “Appendix B, “Memory Map”
Register figure conventions: Minor editorial correction
Table ii, “Acronyms and Abbreviated Terms,” on page 21: Removed entries not used in
this reference manual
Chapter 1, “Overview
Section 1.2, “Chip: Minor formatting change
Updated Section 1.4, “Features
Updated SPC560P40/34 block diagram
Section 1.6, “Chip-level features: Editorial updates
Chapter 3, “Signal Description
Section 2.3, “64-pin LQFP pinout: Removed sentence introducing figures
Section 3.4.3, “Pin muxing: Minor editorial change
4, “Clock Description
Reformatted SPC560P40/34 system clock generation
Updated SPC560P40/34 system clock distribution Part B
CR field descriptions: Corrected field name: was NDIVNDIV; is NDIV
6, “Mode Entry Module (MC_ME)
Section 6.4.4, “Protection of Mode Configuration Registers: Added bullet “
The 4 MHz
crystal oscillator must be on if the system PLL is on.
Therefore, when writing a
‘1’ to PLL0ON, a ‘1’ must also be written to XOSC0ON.”
7, “Power Control Unit (MC_PCU): Unchanged from previous revision
8, “Reset Generation Module (MC_RGM): Unchanged from previous revision
9, “Interrupt Controller (INTC)
Removed MC_ prefixes:
– was MC_ME; is ME
– was MC_RGM; is RGM
Section 9.6, “Functional description: Replaced “INTC_PSR211” with “INTC_PSR221” in
note
10, “System Status and Configuration Module (SSCM): Unchanged from previous
revision
11, “System Integration Unit Lite (SIUL)
Section , “External interrupt request input pins (EIRQ[0:24]): Replaced SIU_ with SIUL_
MCU ID Register #1 (MIDR1): Updated reset value for field PKG[4:0] in bitmap
