RM0046 Cross Triggering Unit (CTU)
Doc ID 16912 Rev 5 619/936
0x0052 CLR20—Commands List Register 20 on page 24-631
0x0054 CLR21—Commands List Register 21 on page 24-631
0x0056 CLR22—Commands List Register 22 on page 24-631
0x0058 CLR23—Commands List Register 23 on page 24-631
0x005A CLR24—Commands List Register 24 on page 24-631
0x005C—0x006B Reserved
0x006C FDCR — FIFO DMA Control Register on page 24-632
0x0070 FCR — FIFO Control Register on page 24-633
0x0074 FTH — FIFO Threshold Register on page 24-634
0x0078–0x007B Reserved
0x007C FST — FIFO Status Register on page 24-635
0x0080 FR0 — FIFO Right aligned data register 0 on page 24-636
0x0084 FR1 — FIFO Right aligned data register 1 on page 24-636
0x0088 FR2 — FIFO Right aligned data register 2 on page 24-636
0x008C FR3 — FIFO Right aligned data register 3 on page 24-636
0x0080–0x009F Reserved
0x00A0 FL0 — FIFO Left aligned data register 0 on page 24-637
0x00A4 FL1 — FIFO Left aligned data register 1 on page 24-637
0x00A8 FL2 — FIFO Left aligned data register 2 on page 24-637
0x00AC FL3 — FIFO Left aligned data register 3 on page 24-637
0x00B0–0x00BF Reserved
0x00C0 CTUEFR — Cross Triggering Unit Error Flag Register on page 24-637
0x00C2 CTUIFR — Cross Triggering Unit Interrupt Flag Register on page 24-638
0x00C4 CTUIR — Cross Triggering Unit Interrupt Register on page 24-639
0x00C6 COTR — Control ON-Time Register on page 24-640
0x00C8 CTUCR — Cross triggering unit control register on page 24-641
0x00CA CTUDF — Cross Triggering Unit Digital Filter register on page 24-642
0x00CC CTUPCR — Cross Triggering Unit Power Control Register on page 24-642
0x00CE–0x3FFF Reserved
Table 312. CTU memory map (continued)
Offset from
CTU_BASE
(0xFFE0_C000)
Register Location
