Cross Triggering Unit (CTU) RM0046
618/936 Doc ID 16912 Rev 5
0x0008 T1CR — Trigger 1 Compare Register on page 24-624
0x000A T2CR — Trigger 2 Compare Register on page 24-624
0x000C T3CR — Trigger 3 Compare Register on page 24-624
0x000E T4CR — Trigger 4 Compare Register on page 24-624
0x0010 T5CR — Trigger 5 Compare Register on page 24-624
0x0012 T6CR — Trigger 6 Compare Register on page 24-624
0x0014 T7CR — Trigger 7 Compare Register on page 24-624
0x0016 TGSCCR — TGS Counter Compare Register on page 24-625
0x0018 TGSCRR — TGS Counter Reload Register on page 24-625
0x001A Reserved
0x001C CLCR1 — Commands List Control Register 1 on page 24-626
0x0020 CLCR2 — Commands List Control Register 2 on page 24-626
0x0024 THCR1 — Trigger Handler Control Register 1 on page 24-627
0x0028 THCR2 — Trigger Handler Control Register 2 on page 24-629
0x002C CLR1—Commands List Register 1 on page 24-631
0x002E CLR2—Commands List Register 2 on page 24-631
0x0030 CLR3—Commands List Register 3 on page 24-631
0x0032 CLR4—Commands List Register 4 on page 24-631
0x0034 CLR5—Commands List Register 5 on page 24-631
0x0036 CLR6—Commands List Register 6 on page 24-631
0x0038 CLR7—Commands List Register 7 on page 24-631
0x003A CLR8—Commands List Register 8 on page 24-631
0x003C CLR9—Commands List Register 9 on page 24-631
0x003E CLR10—Commands List Register 10 on page 24-631
0x0040 CLR11—Commands List Register 11 on page 24-631
0x0042 CLR12—Commands List Register 12 on page 24-631
0x0044 CLR13—Commands List Register 13 on page 24-631
0x0046 CLR14—Commands List Register 14 on page 24-631
0x0048 CLR15—Commands List Register 15 on page 24-631
0x004A CLR16—Commands List Register 16 on page 24-631
0x004C CLR17—Commands List Register 17 on page 24-631
0x004E CLR18—Commands List Register 18 on page 24-631
0x0050 CLR19—Commands List Register 19 on page 24-631
Table 312. CTU memory map (continued)
Offset from
CTU_BASE
(0xFFE0_C000)
Register Location
