Cross Triggering Unit (CTU) RM0046

628/936 Doc ID 16912 Rev 5

T2_ADCE

Trigger 2 ADC command output enable

0 Disabled

1Enabled

T1_E

Trigger 1 enable

0 Disabled

1Enabled

T1_ETE

Trigger 1 External Trigger output enable

0 Disabled

1Enabled

T1_T1E

Trigger 1 Timer 1 output enable

0 Disabled

1Enabled

T1_T0E

Trigger 1 Timer 0 output enable

0 Disabled

1Enabled

T1_ADCE

Trigger 1 ADC command output enable

0 Disabled

1Enabled

T0_E

Trigger 0 enable

0 Disabled

1Enabled

T0_ETE

Trigger 0 External Trigger output enable

0 Disabled

1Enabled

T0_T1E

Trigger 0 Timer 1 output enable

0 Disabled

1Enabled

T0_T0E

Trigger 0 Timer 0 output enable

0 Disabled

1Enabled

T0_ADCE

Trigger 0 ADC command output enable

0 Disabled

1Enabled

Table 324. THCR1 field descriptions (continued)

Field Description
