eTimer RM0046
708/936 Doc ID 16912 Rev 5
0x003E FILT—Input Filter Register on page 26-725
eTimer Channel 2
0x0040 COMP1—Compare Register 1 on page 26-710
0x0042 COMP2—Compare Register 2 on page 26-711
0x0044 CAPT1—Capture Register 1 on page 26-711
0x0046 CAPT2—Capture Register 2 on page 26-712
0x0048 LOAD—Load Register on page 26-712
0x004A HOLD—Hold Register on page 26-713
0x004C CNTR—Counter Register on page 26-713
0x004E CTRL1—Control Register 1 on page 26-714
0x0050 CTRL2—Control Register 2 on page 26-716
0x0052 CTRL3—Control Register 3 on page 26-718
0x0054 STS—Status Register on page 26-719
0x0056 INTDMA—Interrupt and DMA Enable Register on page 26-721
0x0058 CMPLD1—Comparator Load Register 1 on page 26-722
0x005A CMPLD2—Comparator Load Register 2 on page 26-722
0x005C CCCTRL—Compare and Capture Control Register on page 26-723
0x005E FILT—Input Filter Register on page 26-725
eTimer Channel 3
0x0060 COMP1—Compare Register 1 on page 26-710
0x0062 COMP2—Compare Register 2 on page 26-711
0x0064 CAPT1—Capture Register 1 on page 26-711
0x0066 CAPT2—Capture Register 2 on page 26-712
0x00068 LOAD—Load Register on page 26-712
0x006A HOLD—Hold Register on page 26-713
0x006C CNTR—Counter Register on page 26-713
0x006E CTRL1—Control Register 1 on page 26-714
0x0070 CTRL2—Control Register 2 on page 26-716
0x0072 CTRL3—Control Register 3 on page 26-718
0x0074 STS—Status Register on page 26-719
0x0076 INTDMA—Interrupt and DMA Enable Register on page 26-721
0x0078 CMPLD1—Comparator Load Register 1 on page 26-722
0x007A CMPLD2—Comparator Load Register 2 on page 26-722
Table 364. eTimer memory map (continued)
Offset from
eTIMER0_BASE
(FFE1_8000)
Register Location
