ST SPC560P34 - Page 709

RM0046 eTimer
Doc ID 16912 Rev 5 709/936
0x007C CCCTRL—Compare and Capture Control Register on page 26-723
0x007E FILT—Input Filter Register on page 26-725
eTimer Channel 4
0x0080 COMP1—Compare Register 1 on page 26-710
0x0082 COMP2—Compare Register 2 on page 26-711
0x0084 CAPT1—Capture Register 1 on page 26-711
0x0086 CAPT2—Capture Register 2 on page 26-712
0x0088 LOAD—Load Register on page 26-712
0x008A HOLD—Hold Register on page 26-713
0x008C CNTR—Counter Register on page 26-713
0x008E CTRL1—Control Register 1 on page 26-714
0x0090 CTRL2—Control Register 2 on page 26-716
0x0092 CTRL3—Control Register 3 on page 26-718
0x0094 STS—Status Register on page 26-719
0x0096 INTDMA—Interrupt and DMA Enable Register on page 26-721
0x0098 CMPLD1—Comparator Load Register 1 on page 26-722
0x009A CMPLD2—Comparator Load Register 2 on page 26-722
0x009C CCCTRL—Compare and Capture Control Register on page 26-723
0x009E FILT—Input Filter Register on page 26-725
eTimer Channel 5
0x00A0 COMP1—Compare Register 1 on page 26-710
0x00A2 COMP2—Compare Register 2 on page 26-711
0x00A4 CAPT1—Capture Register 1 on page 26-711
0x00A6 CAPT2—Capture Register 2 on page 26-712
0x00A8 LOAD—Load Register on page 26-712
0x00AA HOLD—Hold Register on page 26-713
0x00AC CNTR—Counter Register on page 26-713
0x00AE CTRL1—Control Register 1 on page 26-714
0x00B0 CTRL2—Control Register 2 on page 26-716
0x00B2 CTRL3—Control Register 3 on page 26-718
0x00B4 STS—Status Register on page 26-719
0x00B6 INTDMA—Interrupt and DMA Enable Register on page 26-721
0x00B8 CMPLD1—Comparator Load Register 1 on page 26-722
Table 364. eTimer memory map (continued)
Offset from
eTIMER0_BASE
(FFE1_8000)
Register Location
