Interrupt Controller (INTC) RM0046

224/936 Doc ID 16912 Rev 5

93 0x0974 Reserved

DSPI1

0x0978

DSPI_SR[TFUF]

DSPI_SR[RFOF]

DSPI_1

95 0x097C DSPI_SR[EOQF] DSPI_1

96 0x0980 DSPI_SR[TFFF] DSPI_1

97 0x0984 DSPI_SR[TCF] DSPI_1

98 0x0988 DSPI_SR[RFDF] DSPI_1

LINFlex1

99 0x098C LINFlex_RXI LINFlex_1

100 0x0990 LINFlex_TXI LINFlex_1

101 0x0994 LINFlex_ERR LINFlex_1

102 0x0998 Reserved

103 0x099C Reserved

104 0x09A0 Reserved

105 0x09A4 Reserved

106 0x09A8 Reserved

107 0x09AC Reserved

108 0x09B0 Reserved

109 0x09B4 Reserved

110 0x09B8 Reserved

111 0x09BC Reserved

112 0x09C0 Reserved

113 0x09C4 Reserved

DSPI2

114

0x09C8

DSPI_SR[TFUF]

DSPI_SR[RFOF]

DSPI_2

115 0x09CC DSPI_SR[EOQF] DSPI_2

116 0x09D0 DSPI_SR[TFFF] DSPI_2

117 0x09D4 DSPI_SR[TCF] DSPI_2

118 0x09D8 DSPI_SR[RFDF] DSPI_2

119 0x09DC Reserved

120 0x09E0 Reserved

121 0x09E4 Reserved

Table 75. Interrupt vector table (continued)
