DMA Channel Mux (DMA_MUX) RM0046
434/936 Doc ID 16912 Rev 5
#include "registers.h"
:
:
*CHCONFIG2 = 0x00;
*CHCONFIG2 = 0xC5;
Enabling a source without periodic triggering:
1. Determine with which DMA channel the source will be associated. Remember that only
DMA channels 0–7 have periodic triggering capability.
2. Clear the ENBL and TRIG bits of the DMA channel.
3. Ensure that the DMA channel is properly configured in the DMA. The DMA channel
may be enabled at this point.
4. Select the source to be routed to the DMA channel. Write to the corresponding
CHCONFIG register, ensuring that the ENBL is set and the TRIG bit is cleared.
Example 9Configure source #5 Transmit for use with DMA Channel 2, with no
periodic
triggering capability.
1. Write 0x00 to CHCONFIG2 (Base Address + 0x02).
2. Configure Channel 2 in the DMA, including enabling the channel.
3. Write 0x85 to CHCONFIG2 (Base Address + 0x02).
The following code example illustrates steps 1 and 3 above:
In File registers.h:
#define DMAMUX_BASE_ADDR 0xFC084000/* Example only ! */
/* Following example assumes char is 8-bits */
volatile unsigned char *CHCONFIG0 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0000);
volatile unsigned char *CHCONFIG1 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0001);
volatile unsigned char *CHCONFIG2 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0002);
volatile unsigned char *CHCONFIG3 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0003);
volatile unsigned char *CHCONFIG4 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0004);
volatile unsigned char *CHCONFIG5 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0005);
volatile unsigned char *CHCONFIG6 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0006);
volatile unsigned char *CHCONFIG7 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0007);
volatile unsigned char *CHCONFIG8 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0008);
volatile unsigned char *CHCONFIG9 = (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x0009);
volatile unsigned char *CHCONFIG10= (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x000A);
volatile unsigned char *CHCONFIG11= (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x000B);
volatile unsigned char *CHCONFIG12= (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x000C);
volatile unsigned char *CHCONFIG13= (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x000D);
volatile unsigned char *CHCONFIG14= (volatile unsigned char *)
(DMAMUX_BASE_ADDR+0x000E);
