RM0046 Introduction
Doc ID 16912 Rev 5 49/936
SPC560P40/34 is available in two configurations having different features: Full-featured and
airbag. Tabl e 2 shows the main differences between the two versions of the SPC560P40
MCU.
INTC (interrupt controller) channels 120
PIT (periodic interrupt timer) 1 (with four 32-bit timers)
eDMA (enhanced direct memory access) channels 16
FlexCAN (controller area network) 1
(1)
2
1,(2)
Safety port No
Yes (via second FlexCAN
module)
FCU (fault collection unit) Yes
CTU (cross triggering unit) Yes Yes
eTimer 1 (16-bit, 6 channels)
FlexPWM (pulse-width modulation) channels
8
(capture capabity not
supported)
8
(capture capability not
supported)
Analog-to-digital converter (ADC) 1 (10-bit, 16 channels)
LINFlex
2
(1 × Master/Slave,
1 × Master only)
2
(1 × Master/Slave,
1 × Master only)
DSPI (deserial serial peripheral interface) 2 3
CRC (cyclic redundancy check) unit Yes
Junction temperature sensor No
JTAG controller Yes
Nexus port controller (NPC) Yes (Nexus Class 1)
Supply
Digital power supply
(3)
3.3 V or 5 V single supply with external transistor
Analog power supply 3.3 V or 5 V
Internal RC oscillator 16 MHz
External crystal oscillator 4–40 MHz
Packages
LQFP64
LQFP100
Temperature Standard ambient temperature –40 to 125 °C
1. Each FlexCAN module has 32 message buffers.
2. One FlexCAN module can act as a safety port with a bit rate as high as 8 Mbit/s at 64 MHz.
3. The different supply voltages vary according to the part number ordered.
Table 1. SPC560P40/34 device comparison (continued)
Feature
SPC560P34
Full-featured
SPC560P40
Full-featured
