SPC560P40/34 memory map RM0046
70/936 Doc ID 16912 Rev 5
0xC3FF_0000 0xC3FF_3FFF 16 Periodic Interrupt Timer (PIT)
0xC3FF_4000 0xC3FF_FFFF 48 Reserved
0xFFE0_0000 0xFFE0_3FFF 16 Analog to Digital Converter 0 (ADC_0)
0xFFE0_4000 0xFFE0_BFFF 32 Reserved
0xFFE0_C000 0xFFE0_FFFF 16 CTU_0
0xFFE1_0000 0xFFE1_7FFF 32 Reserved
0xFFE1_8000 0xFFE1_BFFF 16 eTimer_0
0xFFE1_C000 0xFFE2_3FFF 32 Reserved
0xFFE2_4000 0xFFE2_7FFF 16 FlexPWM_0
0xFFE2_8000 0xFFE3_FFFF 96 Reserved
0xFFE4_0000 0xFFE4_3FFF 16 LINFlex_0
0xFFE4_4000 0xFFE4_7FFF 16 LINFlex_1
0xFFE5_0000 0xFFE6_7FFF 128 Reserved
0xFFE6_8000 0xFFE6_BFFF 16 Cyclic Redundancy Check (CRC)
0xFFE6_C000 0xFFE6_FFFF 16 Fault Collection Unit (FCU)
0xFFE7_0000 0xFFE7_FFFF 64 Reserved
0xFFE8_0000 0xFFEF_FFFF 512 Mirrored (range 0xC3F8_0000 – 0xC3FF_FFFF)
0xFFF0_0000 0xFFF3_7FFF 224 Reserved
0xFFF3_8000 0xFFF3_BFFF 16 Software Watchdog (SWT_0)
0xFFF3_C000 0xFFF3_FFFF 16 System Timer Module (STM_0)
0xFFF4_0000 0xFFF4_3FFF 16 Error Correction Status Module (ECSM)
0xFFF4_4000 0xFFF4_7FFF 16 Enhanced Direct Memory Access Controller (eDMA)
0xFFF4_8000 0xFFF4_BFFF 16 Interrupt Controller (INTC)
0xFFF4_C000 0xFFF8_FFFF 272 Reserved
0xFFF9_0000 0xFFF9_3FFF 16 DSPI_0
0xFFF9_4000 0xFFF9_7FFF 16 DSPI_1
0xFFF9_8000 0xFFF9_BFFF 16 DSPI_2
0xFFF9_C000 0xFFFB_FFFF 144 Reserved
0xFFFC_0000 0xFFFC_3FFF 16 FlexCAN_0 (CAN0)
0xFFFC_4000 0xFFFD_BFFF 96 Reserved
0xFFFD_C000 0xFFFD_FFFF 16 DMA Multiplexer (DMA_MUX)
0xFFFE_0000 0xFFFE_7FFF 32 Reserved
0xFFFE_8000 0xFFFE_BFFF 16 Safety Port (FlexCAN)
Table 3. Memory map (continued)
Start address End address
Size
(KB)
Region name
