RM0046 Signal Description
Doc ID 16912 Rev 5 89/936
PWM (OUT_TRIG0_3) CTU (PWM_ODD_3) OUT_TRIG0 sub-module 3
PWM (OUT_TRIG1_3) CTU (PWM_EVEN_3) OUT_TRIG1 sub-module 3
PWM (PWMX3) CTU (PWM_REAL_3) —
PWM (PWMA0) SIU lite —
PWM (PWMB0) SIU lite —
PWM (PWMX1) SIU lite —
PWM (PWMA1) SIU lite —
PWM (PWMB1) SIU lite —
PWM (PWMX2) SIU lite —
PWM (PWMA2) SIU lite —
PWM (PWMB2) SIU lite —
PWM (PWMX3) SIU lite —
PWM (PWMA3) SIU lite —
PWM (PWMB3) SIU lite —
PWM (PWMX3) SIU lite —
eTimer_0 (T1) PWM (EXT_FORCE) —
eTimer_0 (T2) CTU (ETMR0_IN) —
eTimer_0 (T5) ADC_0
ADC injected conversion request signal (for non CTU mode of
operation)
CTU (ETIMER0_TRG) eTimer_0 (AUX_0) —
CTU (ETIMER1_TRG) eTimer_0 (AUX_1) —
CTU (TRIGGER_0)
ADC_0 (through
CTU/ADC IP Interface)
—
CTU (TRIGGER_1)
Virtual ADC_1 (through
CTU/ADC IP Interface)
—
CTU (ADC_CMD_0)
ADC_0 (through
CTU/ADC IP Interface)
16-bit signal
CTU (ADC_CMD_1)
Virtual ADC_1 (through
CTU/ADC IP Interface)
16-bit signal
CTU (EXT_TGR) SIU lite —
ADC_0 (EOC) CTU (NEXT_CMD_0)
End Of Conversion should be used as next command request
signal
Virtual ADC_1 (EOC)
CTU (NEXT_CMD_1)
(through CTU/ADC IP
Interface)
End Of Conversion should be used as next command request
signal
ADC_0 CTU (FIFO_0) 18-bit signal
Virtual ADC_1
CTU (FIFO_1) (through
CTU/ADC IP Interface)
18-bit signal
Table 7. CTU / ADC / FlexPWM / eTimer connections (continued)
Source module
(Signal)
Target module
(Signal)
Comment
