RM0046 Document revision history
Doc ID 16912 Rev 5 935/936
12-Mar-2012
4
cont’d
Chapter 27: Functional Safety:
Figure 433 (SWT Counter Output register (SWT_CO)): changed the access permission
from read/write to read only
Table 394 (SWT_TO field descriptions): updated fied description, was
(SWT_CR.WENSWT_CR.=0) is (SWT_CR[WEN]=0).
Chapter 33: Boot Assist Module (BAM)
Table 435 (Hardware configuration to select boot mode): rewrote the column title from
“ABS[2,0]” to ABS[1:0] removed footnote stating: ABS[1] is “don’t care”
Section 33.5.1, Entering boot modes : added PAD A[2] note, added the Boot
Configuration Pins.
Table 435 (Hardware configuration to select boot mode) : Added footnote, “During reset
the boot configuration pins are weak pull down.”
Added Section 33.5.2, SPC560P40/34 boot pins.
Updated Section , Configuration with new Figure 487 (BAM Autoscan code flow).
Section , Boot from UART with autobaud enabled : Updated "UART boot mode" with
“FlexCAN boot mode”.
Added Section 33.7, Censorship
Chapter 34: Voltage Regulators and Power Supplies:
Updated Section 34.1.1, High Power or Main Regulator (HPREG)
Chapter 35: IEEE 1149.1 Test Access Port Controller (JTAGC):
Updated Section 35.9, e200z0 OnCE controller to remove reference of Nexus2+
configuration registers.
Updated Table 457 (e200z0 OnCE register addressing): Nexus 2+ Access was replaced
with “Reserved”.
Chapter 36: Nexus Development Interface (NDI):
Removed the following sections :
- All sections between Section 36.8, “Interrupts and Exceptions and Section 36.9, “Debug
support overview.
- Section 36.26.2, “Nexus Messaging”.
- Section 36.8.1, “Hardware Implementation Dependent Register 0 (HID0)”.
Section 36.4, “Features: Removed the following features they are not supported by Nexus
Class 1:
- Program Trace
- Ownershipe Trace
- Watchpoint messaging
- Watchpoint trigger
- Registers for program trace, ownership trace, and watchpoint trigger
- Run-time access to the on-chip memory map
Updated Figure 504, NDI functional block diagram.
Section 36.9.1, Software Debug Facilities: removed cross-reference at “Debug Interrupt
(IVOR15)” section.
17-Sep-2013 5 Updated Disclaimer
Table 476. Revision history (continued)
Date Revision Changes
