RM0046 Registers Under Protection
Doc ID 16912 Rev 5 921/936
eTimer 0 CH5_CTRL3 16 0x00B2 16-bit
eTimer 0 CH5_CCCTRL 16 0x00BC 16-bit
FlexPWM—Base address: 0xFFE2_4000
41 registers to protect
FlexPWM SUB0_CTRL2 16 0x0004 16-bit
FlexPWM SUB0_CTRL 16 0x0006 16-bit
FlexPWM SUB0_OCTRL 16 0x0018 16-bit
FlexPWM SUB0_INTEN 16 0x001C 16-bit
FlexPWM SUB0_DMAEN 16 0x001E 16-bit
FlexPWM SUB0_TCTRL 16 0x0020 16-bit
FlexPWM SUB0_DISMAP 16 0x0022 16-bit
FlexPWM SUB0_DTCNT0 16 0x0024 16-bit
FlexPWM SUB0_DTCNT1 16 0x0026 16-bit
FlexPWM SUB1_CTRL2 16 0x0054 16-bit
FlexPWM SUB1_CTRL 16 0x0056 16-bit
FlexPWM SUB1_OCTRL 16 0x0068 16-bit
FlexPWM SUB1_INTEN 16 0x006C 16-bit
FlexPWM SUB1_DMAEN 16 0x006E 16-bit
FlexPWM SUB1_TCTRL 16 0x0070 16-bit
FlexPWM SUB1_DISMAP 16 0x0072 16-bit
FlexPWM SUB1_DTCNT0 16 0x0074 16-bit
FlexPWM SUB1_DTCNT1 16 0x0076 16-bit
FlexPWM SUB2_CTRL2 16 0x00A4 16-bit
FlexPWM SUB2_CTRL 16 0x00A6 16-bit
FlexPWM SUB2_OCTRL 16 0x00B8 16-bit
FlexPWM SUB2_INTEN 16 0x00BC 16-bit
FlexPWM SUB2_DMAEN 16 0x00BE 16-bit
FlexPWM SUB2_TCTRL 16 0x00C0 16-bit
FlexPWM SUB2_DISMAP 16 0x00C2 16-bit
FlexPWM SUB2_DTCNT0 16 0x00C4 16-bit
FlexPWM SUB2_DTCNT1 16 0x00C6 16-bit
FlexPWM SUB3_CTRL2 16 0x00F4 16-bit
FlexPWM SUB3_CTRL 16 0x00F6 16-bit
Table 475. Registers under protection (continued)
Module Register Register size (bits) Register offset Protected bitfields
