General Configuration Command Set
Managing Configuration and Image Files
2-132 Matrix DFE-Platinum and Diamond Series Configuration Guide
Table 2-8 dir Output Details
Output What It Displays...
Images Lists all the images resident in the chassis and information
about each.
Filename Name of the image file stored in the local file system.
Various flags may be listed after the filename, including:
• (active) - Indicates this image is currently running.
• (boot) - Indicates this image is selected to boot on the
next reset.
Version Firmware version of the image.
Size Size of image file in the local file system.
Date Date of image file in the local file system.
CheckSum MD5 checksum calculated across the entire image file, used
for image identity and verification.
Location Modules on which this image resides. The system
automatically mirrors all images to all other compatible
modules in the system. A user cannot selectively add or
remove images from individual modules while they reside
in the same chassis.
Compatibility Module types on which this image is qualified to run.
Attempting to run an incompatible image on a given
module will not succeed.
Files User maintained files, such as CLI configuration files. For
details on working with configuration files, refer to show
config (Section 2.2.9.3) and configure (Section 2.2.9.4.)
SlotN Lists user maintained files by slot location.
