IP Configuration Command Set
Configuring PIM
Matrix DFE-Platinum and Diamond Series Configuration Guide 12-65
12.2.7.11 show ip mroute
Use this command to display the IP multicast routing table. This table shows how a multicast
routing protocol, such as PIM and DVMRP, will forward a multicast packet. Information in the table
includes source network/mask and upstream neighbors. For more information on configuring
DVMRP, refer to Section 13.2.4.
show ip mroute [unicast source address | multicast group address] [summary]
Syntax Description
Command Type
Router command.
Command Mode
Any router mode.
Command Defaults
If no optional parameters are specified, detailed information about all source and
destination addresses will be displayed.
unicast source
address | multicast
group address
(Optional) Displays information about a specific unicast
source address or multicast destination address.
summary (Optional) Displays a summary of information.
