Spanning Tree Configuration Command Set
Configuring Spanning Tree Port Parameters
6-116 Matrix DFE-Platinum and Diamond Series Configuration Guide
6.2.2.24 show spantree operpoint
Use this command to display the operating point-to-point status of the LAN segment attached to a
port.
show spantree operpoint [port port-string]
Syntax Description
Command Defaults
If not specified, status will be displayed for all ports.
Command Type
Switch command.
Command Mode
Read-Only.
Example
This example shows how to display the point-to-point status operating of the LAN segment attached
to fe.2.7:
port port-string (Optional) Displays point-to-point operating status for
specific port(s). For a detailed description of possible
port-string values, refer to Section 4.1.1.
Matrix(rw)->show spantree operpoint port fe.2.7
Port fe.2.7 has a Port Oper Point to Point of False on SID 1
